Syrup Molasses Use 18 Tons 20 Tons Bottom Loading and Bottom Discharging Bulk Flexitank
ADA offer Syrup Molasses Use 18 Tons 20 Tons Bottom Loading and Bottom Discharging Bulk Flexitank.
Flexitank with capacity from 16000L to 26000L, 24000L is the most popular capacity; there are three types according to valve: Top Loading and Top Discharging(TLTD), Bottom Loading and Bottom Discharging(BLBD), Top Loading and Bottom Discharging(TLBD).
Competitive Advantage:
1. Compare with ISO Tanks-- Same volume, ADA flexitank with lower sea freight, lower storage charge and without rent cost.
2. Compare with drums-- One 20ft container can load 24000L liquids by flexitank, but it can only load 16000L if buy drums, same sea freight ADA flexitank can load 8000L more liquids in one 20ft container.
3. ADA Valve-- The special design of the 3'' food grade ball valve, make the residue less than 10 kgs when discharging and it's more safety with lock and special flange design.
4. Easy Operation-- For flexitank, two people with one hour can accomplish all the loading and unloading work, save time and save labor.
5. Wide application-- Suitable to different kinds of non-hazardous liquid products.
6. Material-- All material including PE, PP are brand new material.
Specifications:
| Capacity |
16000L to 26000L
|
| Material |
LDPE, PP
|
| Layers |
3 layers PE and 1 layer PP
4 layers PE and 1 layer PP
|
| Valve |
3'' Ball valve
3’’ Butterfly valve
|
| Type |
Top Loading and Top Discharging(TLTD)
|
|
Bottom Loading and Bottom Discharging(BLBD)
|
|
Top Loading and Bottom Discharging(TLBD)
|
| Accessories |
Steel bars, bulkhead, corrugated paper
|
| Air vent |
Available
|
| Heating Pad |
Available
|
| Insurance |
USD 5000 000 Global Quality Liability Insurance
|
| Certificates |
COA, AAR, ISO9001, HALAL, KOSHER, FDA, EC
|
| Approval shipping lines |
Maersk Line, CMA CGM, Yang Ming Line, Wanhai, KMTC, APL, HMM, Hapag-Lloyd...
|
| Temperature resistance | -20℃--70℃ |
| Applications: |
| Foodstuffs | Palm oil, Sunflower oil, Edible oil, Vegetable oil, Olive oil, Grape wine, Sorbitol, Soy sauce, Fruit juices, Food additives, Wine, Mineral, Glucose, Malt, Syrup and so on. |
| Industrial Oils | Base oil, Lubricant, Transformer oil, White oil, Tung-oil, Glycerin, Coconut butter, Hydraulic oil, Used cooking oil, Grease, Gear oil, Ricinus oil, High fatty acids and oleic acid etc. |
| Non-hazardous liquid chemicals | Plasticizers, Synthetic resins, Detergents, Disinfectors, Surface active agents, Polyhydric alcohols, Feed additives, Silicate, Salt Solution, Glycols, Emulsions, Polyether, Alkylating agent, Fertilizers, Natural& synthetic latex etc |
2. FAQ
1. What Shipping lines accept your flexitank?
We are member of COA, have passed American Railway Impact test, almost all shipping lines accept ADA brand flexitank, such as Maersk Lines, CMA-CGM, YML, Wanhai, KMTC, Hapag-Lloyd, APL....
2. If there is leakage in abroad, how to solve it?
Except insurance, we have worldwide agent.
3. How many empty flexitank can be loaded in container?
One 20ft container can load 70 sets flexitank with accessories, one 40HQ can load 165 sets.
4. What’s the loading port?
Qingdao, China
